WELDMAX VERSITEC 250I SERIES 2 - SYNERGIC MIG/TIG/MMA
Key Features & Benefits:
- Synergic Control - Easy to set with plate thickness program
- Gas or Gasless wire capability
- Euro torch Connection - Euro torches are the most common and best connector in the market
- VRD Fitted
- Line Voltage Compensation
- Hot Start in Stick welding mode
- Anti-Stick - Stick welding function
- Lift Arc - TIG welding start system
- CE & C-TICK Certified.
- Generator Friendly - 7.5kVA Minimum generator
COMPLETE MACHINE PACKAGE READY TO WELD INCLUDING:
- Weldmax 250i Inverter MIG power source
- 4 metre Mig Torch setup for Steel
- Earth Lead 4 Metre with Spring clamp
- Argon Regulator with 1.5mtr gas Hose
- Drive Rollers to suit Steel/Stainless
- 15A/240V phase plug fitted
- Owners manual
- 3 year warranty
- Lifetime product support
The Weldmax 250i Synergic MIG-TIG-STICK welding system is a lightweight single phase high performing multi-process welder. A microprocessor controlled inverter machine suitable DC controlled MIG/MAG, TIG and MMA (stick) which guarantees excellent stability of the welding arc with minimal spatter. In MMA mode the microprocessor controls the Hot Start, Arc Force & anti-sticking functions. In TIG mode it controls the Lift Arc function and in the MIG mode it allows either manual or fully synergic welding. Regulation of the slope-up motor with automatic soft start wire feed control of the arc makes it ideal for use in auto repair shops, light fabrication workshops and onsite maintenance work.
SPECIFICATIONS:
- Input Power: 240V/1Ph/50-60Hz
- Input Power @60% Duty Cycle: 7.5Kva
- Amperage (Min/Max):
- MIG 10-250A
- TIG 5-250A
- MMA 5-200A
- Wire Dia Range: 0.8mm -1.2mm
- Electrode Range: 1.6mm -4.0mm
- Dimensions (mm): 600L x 225W x 480H
- Weight: 28kg
DUTY CYCLE RATINGS:
- MIG 50%@250A / 60%@225A / 100%@175A
- TIG 50%@250A / 60%@225A / 100%@175A
- MMA 45%@200A / 60%@175A / 100%@135A
All the functions can easily be selected from the front panel and digital display shows the welding voltage and current parameters. The Weldmax 250i accepts 200mm & 300mm diameter spools.
A very impressive and compact industrial performer with years of quality welding to be done..... see it for yourself and request a demonstration in your workshop or at the QWS Demonstration Centre at Bulimba Queensland.
