Part No: EHY31620

Availability: 3 In stock, ready to be shipped!

2.5kg Pkt
Hyundai S-316L.16N Stainless Steel Electrodes
Welding of extra-low carbon 18%Cr-12%Ni-2%Mo (316L stainless steel)

Characteristics on usage
  • S-316L.16N is a lime-titania type electrode provided with a good usability and weldability. As the all-weld metal has an austenite structure containing proper quantity of ferrite, crack resistibility is good. It has an excellent resistibility to inter-crystalline corrosion in the as-welded condition since carbon content is less and intergranular corrosion resistibility is superior to that of S-316.16N, and as it contains Mo., resistance to heat is also good.
Notes on usage
  • Weaving width should be within two and a half times of electrode’s diameter.
  • Remove all oil and dust from the groove.
  • Dry the electrodes at 350°C (662°F) for 60 minutes before use.
Welding position
  • F, HV, VU, OH
  • AC or DC+
Typical Chemical Composition of all weld metal (%)
 C       Si       Mn       P       S       Cr       Ni       Mo
 .02       .73       1.33       .029       .016       19.4       11.7       2.4
Typical Mechanical Properties of all weld metal
 T.S N/mm2 (lbs/in2)     EL.
 557 (80,900)       45.2
KR, ABS, LR, BV, DNV, NK, CWB This product is priced “per KG”. The minimum quantity available to purchase is shown in the "Pack Qty".
