ALLCLEAR® TA400 Fume Extraction Grinding & Welding Table

Heavy-Duty Downdraft Table for Welding, Grinding, Cutting & Gouging

The ALLCLEAR® TA400 is a heavy-duty mobile downdraft table built for industrial fabrication work. Designed to extract welding and grinding fume directly at the source, it pulls contaminated air down and away from the operator's breathing zone, helping create a safer, cleaner workshop environment for demanding day-to-day use.

Powered by a 2.2kW motor with an internal design engineered for maximum suction efficiency, the TA400 delivers an airflow rate of up to 2,500m³/hr. An automatic filter cleaning system keeps suction performance consistent while reducing manual maintenance, and the cleanable filter offers a longer service life and lower running costs than traditional disposable filters.

Built to handle real fabrication workloads, the TA400 features a spacious 1500 x 700mm downdraft workbench with a heavy-duty 5mm table top and a 500kg load capacity. Hinged side panels allow longer workpieces to be positioned on the table, and a built-in 10A 230V outlet at the front of the table powers grinders and other tools without needing a separate power point.

Key Features

• 2.2kW motor — up to 2,500m³/hr airflow
• Automatic filter cleaning system for consistent suction and less downtime
• Cleanable filter — longer filter life, lower operating costs
• Multi-level spark filtration for processes generating high spark/spatter levels (heavy grinding, welding with heavy material, flux-cored wire, gouging)
• 1500 x 700mm downdraft workbench with heavy-duty 5mm table top
• 500kg load capacity
• Hinged side panels to accommodate longer objects
• Built-in 10A 230V outlet for powering grinders and other tools
• Working hour counter, filter fullness indicator, and malfunction warning
• Mounted on casters for mobility
• Runs on 415V 3-phase power (5-pin plug, 10A or higher)

Specifications

Best Suited For

The TA400 is designed for welding, grinding, cutting, and gouging fume extraction, and is well suited to heavier fabrication work involving flux-cored wire, heavy material welding, and high-spark processes thanks to its multi-level spark filtration.

Note: for frequent or medium-to-heavy oxy or plasma cutting, the TA400 in standard configuration is not recommended without appropriate modifications for hot material/dross management — contact Weldclass for cutting-specific solutions. The TA400 is also not suitable for extracting aluminium dust, oil mist, gases, or water vapour.

Power plug is not included and must be fitted by a qualified electrician, matching the 415V phase rotation wiring of the installation site.

Frequently Asked Questions

What is the ALLCLEAR TA400 used for? The ALLCLEAR TA400 is a heavy-duty mobile downdraft table used to extract welding, grinding, cutting, and gouging fumes at the source, protecting operators and improving air quality in industrial workshops.

What power supply does the TA400 need? The TA400 operates on 415V 3-phase power and requires a 5-pin plug rated at 10A or higher. The plug is not included and should be fitted by a qualified electrician, as phase rotation wiring can vary between facilities.

How much weight can the TA400 table hold? The TA400 has a 500kg load capacity, supported by a heavy-duty 5mm coated steel table top.

Is the TA400 suitable for plasma or oxy cutting? The TA400 in its standard configuration is not recommended for frequent or medium-to-heavy oxy or plasma cutting without appropriate modifications for hot material and dross management. Contact Weldclass for cutting-specific solutions.

Does the TA400 have automatic filter cleaning? Yes. The TA400 is equipped with an automatic filter cleaning system, and uses a cleanable filter for extended filter life and lower ongoing operating costs compared to traditional disposable filters.

What is the difference between the TA400 and the TA100? The TA400 is a heavy-duty table suited to grinding, cutting, and gouging with a 2.2kW motor and 500kg load capacity, while the TA100 is a more compact, lighter-duty table designed for welding and light grinding only, running on standard 230V single-phase power.

What is the difference between the TA400 and the TA500? Both are heavy-duty tables with similar motor and airflow specs, but the TA500 adds backdraft capture in addition to downdraft extraction, giving broader fume coverage for certain applications.

Is the TA400 suitable for aluminium grinding? No. The TA400 should not be used to extract aluminium dust, oil mist, gases, or water vapour, due to fire/explosion risk and potential filter damage.
