PLYMOTH WALL MOUNTED WF-ECO JET PULSE WALL-FILTER 3-PHASE
Plymoth WF-Eco Jet Pulse Wall-Mounted Filter (3-Phase)
Get efficient, self-cleaning fume filtration without the hassle of manual filter servicing. The Plymoth WF-Eco Jet Pulse is a wall-mounted fume and dust filter unit that moves over 1,000 m³/h through an aluminium impeller, with a built-in compressed-air system that cleans the filter cartridge in minutes — door stays shut the whole time, so no dust exposure during cleaning.
Why it matters
A wall-mounted filter unit like the WF-Eco pairs with an extraction arm to give you a complete, self-contained LEV system — capturing fume at the source and filtering it in place rather than exhausting outside. That's a practical option for workshops without external ducting, and the jet-pulse self-cleaning function keeps filtration performance consistent over time rather than degrading between manual cleans. Maintaining strong, consistent capture matters as Australia's welding fume exposure limits tighten under the WES-to-WEL transition, effective 1 December 2026.
Key features
- Jet Pulse self-cleaning filter — built-in compressed air system cleans the filter cartridge in minutes, door closed throughout
- Easy-empty dust tray — large capacity, no tools required, safe and secure emptying
- High airflow — over 1,000 m³/h through the hood via aluminium impeller
- Robust construction — built for workshop duty cycles
- Flexible arm compatibility — pairs with 1.5m, 2m, or 3m flexi extraction arms mounted directly to the base, or can be ducted to a fixed collection point or machinery
- Simple wall installation — 4 mounting holes on the back for direct wall fixing
What's included
- Filtered extraction unit
- High-performance fan
- 360° base-mounted arm system
- Built-in filter and cartridge
- 4m electrical cable
Extraction arms are ordered separately.
Compatible PLYMOTH internally-supported arms:
| Part | Description |
|---|---|
| P-052 | 2m, 160mm diameter |
| P-053 | 3m, 160mm diameter |
| P-054 | 4m, 160mm diameter |
Technical specifications
| Spec | Detail |
|---|---|
| Part number | P-547 |
| Air movement | 1,000 m³/h |
| Input power | 3-phase, 415V (1-phase 240V also available) |
| Cleaning system | Jet Pulse (compressed air) |
| Mounting | Wall, 4-hole fixing |
Typical environments
Welding workshops, confined space work, service and repair bays, manufacturing and maintenance facilities.
FAQ
Does this come with an extraction arm?
No — the WF-Eco is the filter and fan unit only. You'll need to select a compatible arm (P-052, P-053, or P-054) separately based on your reach requirements, or duct the unit to a fixed point.
How does the self-cleaning function work?
A compressed-air fitting pulses air through the filter cartridge to dislodge dust, all while the access door stays closed — so there's no operator exposure to fume dust during cleaning, and no need to remove the filter.
Can I duct this instead of using an arm?
Yes — the WF-Eco can be ducted directly to a collection point or connected to machinery/equipment rather than using a flexi arm, depending on your workshop layout.
Is this the 3-phase or single-phase version?
This listing is the 3-phase (415V) version; a single-phase 240V option is also available if that better suits your site's power supply.
