HYPERTHERM POWERMAX85 SMARTSYNC CPC W/ 7.6MT TORCH

Specifications

• Input Voltages: 200 – 480 V, 1-PH, 50/60 Hz
• Kilowatt Output: 12.2
• Input Current: 200/208/240/480

1-PH 70/68/58/29/ A @ 12.2 kW

200/ 280/240/480/ 600 V

3-PH 42/40/35/18/17 A @ 12.2 kW

• Output Current: 25 – 85A
• Rated Output Voltage: 143 VDC
• Duty Cycle @ 104°F: 60% @ 85 A, 230 – 600 V, 3-Ph

60% @ 85 A, 480 V, 1-PH

50% @ 85 A, 240 V, 1PH

50% @ 85 A, 200 – 208 V, 3-PH

40% @ 85A, 200 – 208 V, 1 - PH

100% @ 66A, 230 – 600 V, 1/3 – PH

• Open Circuit Voltage: 305 VDC
• Dimensions with Handles (mm): 483 x 233 x 430
• Weight: 32kg
• Gas Supply: Clean, Dry, Oil-Free air or Nitrogen
• Optimum Inlet Gas Pressure: 7.6 – 8.3 bar (110 – 120 psi)
• Minimum Inlet Gas Pressure: 5.2 bar (75 psi)
• Recommended Inlet Gas Flow Rate: Cutting – 210 I/min @ 5.9 bar (450 scfh, 7.5

scfm @ 85psi)

Gouging: 210 I/min @ 4.l8 bar (450 scfh, 7.5 scfm @ 70 psi

• Input Power Cable Length: P 3m (10)
• Power Supply Type: Inverter – 1GBT
• Engine Drive Requirement: 20 kW for full 85 output
